Type VCE

Bevel gearbox with clamping set for mounting a servomotor or planetary gearbox

High speeds up to n1 = 6000 1/min – Minimized circumferential backlash (optional) –High precision – Cast iron housing

Features

In contrast to the VC, the VCE has a clamping set instead of a clutch and is optimised to accommodate a planetary gearbox.

Attachment of a servomotor possible

Bevel gearbox with spiral gearing

Gear ratios: i = 1:1 to 6:1

Low-backlash design with up to < 6 angular minutes

Compact design

Maintenance-free
