PRODUCT AREAS
Our all-rounders are the right choice for numerous applications.
Series | Design | Inter thread diameter | Flange | Pressure range | Housing material | Medium temperature | Downloads | |
 | 40 | 2/2-way valve with diaphragm seal | G1/4-G3 13,5-80 mm | -- | 0.3-20 bar | Brass 2.0402 steel 1.4581 | -10 °C/ +80 °C | |
 | 43 | 2/2-way valve with diaphragm seal | G1/4-G2 13,5-50 mm | -- | 0-16 bar | Brass 2.0402 steel 1.4581 | -10 °C/ +80 °C | |
 | 52 | 2/2-way valve with nipple seal | G1/8-G1/2 1-6 mm | -- | 0-90 bar | Brass 2.0401 / 2.0402 Stainless steel 1.4305 / 1.4571 | -10 °C/ +80 °C | |
 | 63 | 2/2-way valve with nipple seal | G1/2-G3 12,5-76 mm | -- | 0-40 bar | Brass 2.0402 Red brass RG5 Stainless steel 1.4408 | -40 °C/ +200 °C |
