PRODUCT AREAS
High pressure valves
Our specialists for the pressure range up to 1,000 bar.
| Series | Design | Inter thread diameter | Flange | Pressure range | Housing material | Medium temperature | Downloads | |
 | 55 | 2/2-way solenoid valve with nipple seal direct acting | G1/4 0.5 - 6.0 mm | -- | 0-900 bar | Brass 2.0401 Stainless steel 1.4301 / 1.4462 / 1.457 | -40 °C/ +80 °C | |
 | 75HD | 3/2-way solenoid valve with nipple seal direct acting | G1/4 1.0 - 5.0 mm | -- | 0-300 bar | Brass 2.0401 Stainless steel 1.4301 (AISI 304) | -30 °C/ +80 °C | |
 | 8/000 | 2/2-way solenoid valve with piston seal pilot operated | G1/4 & G1/2 8 / 15 mm | -- | 5-350 bar | Stainless steel 1.4301 (AISI 304) | -40 °C/ +80 °C | |
 | 2/529 | 2/2-way solenoid valve with piston seal pilot operated | G1/4-G2 12 -50 mm | -- | 1-450 bar | Stainless steel 1.4571 -40 | -40 °C/ +80 °C | |
 | 3/071 | 2/2-way solenoid valve with piston seal pilot operated | G1/4-G1/2 8 mm | -- | 5-900 bar | Stainless steel 1.4462 | -20 °C/ +60 °C | |
 | 2/529pn | 2/2-way valve with piston seal servo pressure controlled | G1/2-G2 13 -50 mm | -- | 1-600 bar | Stainless steel 1.4571 | -40 °C/ +80 °C | |
 | 3/045 | 3/2-way solenoid valve with plate seal direct acting | G1/8-G1/2 | -- | 0-250 bar | Stainless steel 1.4571 | -10 °C/ +80 °C | |
 | 8/100 | 2/2-way valve with plate seal directly pressure controlled | G1/8-G1/4 7/16 UNF - 9/16 UNF 0.5 -8.0 mm | -- | 0-1,000 bar | Stainless steel 1.4301 / 1.4501 | -40 °C/ +80 °C | |
 | 46 | 2/2-way solenoid valve with piston seal pilot operated | G1/4-G1/2 8 mm | -- | 1-100 bar | Stainless steel 1.4581 | -40 °C/ +80 °C | |
 | 1/921 | 3/2-way valve with piston seal directly pressure controlled | G1/4-G1 10-22 mm | -- | 0-500 bar | Stainless steel 1.4581 | -10 °C/ +80 °C | |
 | 52-S | 2/2-way solenoid valve with nipple seal direct acting | G1/4 1-1.5 mm | -- | 0-150 bar | Brass 2.0401 Stainless steel 1.4305 Stainless steel 1.4571 | -20 °C/ +80 °C | |
 | 1/041 FL | 2/2-way solenoid valve with piston seal force pilot operated | -- | DN15 - DN100 | 0-130 bar | Steel C22.8 Stainless steel 1.4408 | -40 °C/ +80 °C | |
 | 1/041 | 2/2-way solenoid valve with piston seal force pilot operated | G1/4-G2 13-50 mm | -- | 0-130 bar | Brass 2.0401 Stainless steel 1.4408 | -40 °C/ +80 °C | |
 | 2/918 | 2/2-way coaxial solenoid valve | G3/8-G2 10-50 mm | -- | 0-100 bar | Brass 2.0401 Stainless steel 1.4305 | -10 °C/ +100 °C | |
 | 3/918 | 3/2-way coaxial solenoid valve | G3/8-G11/4 10-50 mm | -- | 0-64 bar | Brass 2.0401 Stainless steel 1.4305 | -10 °C/ +100 °C |
